Part Number
C17DASH
Size / weight / color
L170mm*ø65mm / 120g / Black
Camera sensor
4M physical pixel CMOS image sensor, Seven groups of all-glass lens
Lens Angle
Front: 165° (horizontal: 130°, vertical: 80°), Rear: 140° (horizontal: 100°, vertical: 70°)
Second camera
Support CVBS signal camera input
WIFI
Built-in WIFI module (IEEE 802.11b/g/n, 2.412 GHz-2.4835 GHz)
Mobile terminal app
Dashguard (IOS V8.0 and above, Android V8.0 and above)
Audio and video format
Video: H.264 video encoding / MOV format; audio: AAC
Storage media
TF high-speed memory card (maximum support 128G, make sure to use CLASS10 and above original genuine card)
Button
Power button/camera button/emergency recording button. Reset Button. Upgrade Button (press the key to enter the upgrade mode when the power is turned off or the card is released)
LED
2 LED (red and blue)
G-Sensor
Built-in triaxial three-dimensional collision acceleration sensor
GPS
Built-in high-quality GPS, support PC-side player track playback
RTC
Connect the device's WIFI, open the App or GPS to locate the automatic sync time
Resolution / Bit rate / Frame rate
1920*1080 16M @30fps / 1280*720 12M @30fps
Upgrade Interface
SD card upgrade (upgrade process power failure or return to the card cannot start, you need to press the upgrade button to enter the upgrade mode)
PC Player
GVP Player
Communication Interface
Reserved UART / IR interface
HDMI interface
Reserved HDMI interface
Alarm I/O
Define input / output alarm line (active low)
Lock
With lock to protect card, tamper resistant
Power
6V-30V car battery or car charger power
Static power consumption
3.6W (one camera) 5.0W (both cameras)
Standby current
Less than 1mA Note: the vehicle is off and after full charge (within 10 min)
Good performance temperature
-25° to 65°
Operating temperature
-30° to + 70°
Storage temperature
-40° to + 90°
Product specifications subject to change on 60-day notice.
