Part Number
C5F214HD
TV System
NTSC
Image Sensor
1/3.2" Sony CMOS Sensor
Resolution
1280(H) X 7960(V), 1.23M, 800TVL
Video Out
AHD 720P
Min. Illumination
0.05 Lux
AGC
Auto (Digital 42dB)
Lens
1.2mm Angle (180 H X 210 D X 125 V)
Lens Distortion
Horizontal Correction Only
WDR
On
Sync.
Internal Sync.
Power Input
DC 5V
Power Consumption
1.5Watt @ 12V /LED On
AES Range
1/60 ~ 1/100,000 sec
S/N Ratio
More Than 50dB (AGC Off)
Operating Temp.
-30°C ~ + 70°C
Storage Temperature
-40°C ~ + 80°C
Dimension & Weight
41 X 29 X 45.5mm/ 1.61" X 1.14" X 1.79" 140.5g / 4.96 oz
Product specifications subject to change on 60-day notice.
